MACHINE TOOLS - End Working Machine - boring machine - Facing head

Boring machine with one or two opposing heads, each equipped with a self-centering clamping system and a facing head spindle (D’Andrea) on each side.

Chamfering/Bevelling, Facing, Drilling, Threading, Turning with Static Piece, Boring, Profiling, Milling

This system enables radial tool movement during machining, allowing for the development of irregular geometries without the need for specialized tools. Our standards include three models with different work areas. Configurable with fully automatic loading/unloading and tool change magazines, this machine ensures maximum flexibility and productivity, making it ideal for complex machining tasks.

Technical specifications

MACHINE TOOLS - End Working Machine - boring machine - Facing head

EWM - Boring Machine - Facing head	T3	T5	T8
D'andrea Facing head	UT 3-360	UT5-630	UT 8 -1000
Max machinable diameter	ø 800 mm	ø 1250 mm	ø 1600 mm
Length	700 ÷12000 mm	700 ÷12000 mm	1000 ÷12000 mm
Max Clamping diameter	ø 800 mm	ø 1250 mm	ø 1600 mm
N° machining unit	1 - 2	1 - 2	1 - 2
Max Spindle rotation speed	500 rpm	250 rpm	160 rpm
Torque	400 da Nm	800 da Nm	1000 da Nm
Stroke Z	600 mm	750 mm	1000 mm
Radial stroke X	120 mm	200 mm	280 mm
Max Radial Force	400 da Nm	500 da Nm	1000 da Nm
Max chip removal (mm^2 C40)	5	9	14
Tool magazine capacity	8	8	8
